| Standard Set | Step ‘mm’ | Range/Size ‘mm’ | Qty (pcs.) | Total qty (pcs.) |
| M 122/1 | – | 1.0005 | 01 | 122 |
| 0.001 | 1.001 – 1.009 | 09 | ||
| 0.01 | 1.01 – 1.49 | 49 | ||
| 0.1 | 1.6 – 1.9 | 04 | ||
| 0.5 | 0.5 – 24.5 | 49 | ||
| 10 | 30 – 100 | 08 | ||
| – | 25,75 | 02 | ||
| M 112/1 | – | 1.0005 | 01 | 112 |
| 0.001 | 1.001 – 1.009 | 09 | ||
| 0.01 | 1.01 – 1.49 | 49 | ||
| 0.5 | 0.5 – 24.5 | 49 | ||
| 25 | 25 – 100 | 04 | ||
| M 103/1 | – | 1.005 | 01 | 103 |
| 0.01 | 1.01 – 1.49 | 49 | ||
| 0.5 | 0.5 – 24.5 | 49 | ||
| 25 | 25 – 100 | 04 | ||
| M 88/1 | – | 1.0005 | 01 | 88 |
| 0.001 | 1.001 – 1.009 | 09 | ||
| 0.01 | 1.01 – 1.49 | 49 | ||
| 0.5 | 0.5 – 9.5 | 19 | ||
| 10 | 10 – 100 | 10 | ||
| M 47/1 | – | 1.005 | 01 | 47 |
| 0.01 | 1.01 – 1.09 | 09 | ||
| 0.1 | 1.1 – 1.9 | 09 | ||
| 1 | 1 – 24 | 24 | ||
| 25 | 25 – 100 | 04 | ||
| M 46/1 | 0.001 | 1.001 – 1.009 | 09 | 46 |
| 0.01 | 1.01 – 1.09 | 09 | ||
| 0.1 | 1.1 – 1.9 | 09 | ||
| 1 | 1 – 9 | 09 | ||
| 10 | 10 – 100 | 10 | ||
| M 32/1 | – | 1.005 | 01 | 32 |
| 0.01 | 1.01 – 1.09 | 09 | ||
| 0.1 | 1.1 – 1.9 | 09 | ||
| 1 | 1 – 9 | 09 | ||
| 10 | 10 – 30 | 03 | ||
| – | 60 | 01 | ||
| M 18/1 | 0.001 | 0.991 – 0.999 | 09 | 18 |
| 0.001 | 1.001 – 1.009 | 09 | ||
| M 9/1 | 0.001 | 1.001 – 1.009 | 09 | 09 |
| M 9 | 0.001 | 0.991 – 0.999 | 09 | 09 |
| M 2/1 (Wear Protector) |
– | 1.00 | 02 | 02 |
| M 2/2 (Wear Protector) |
– | 2.00 | 02 | 02 |
| M 10 (Wear Protector) |
– | 2.5, 5.1, 7.7, 10.3, 12.9, 15, 17.6, 20.2, 22.8, 25 | 10 | 10 |
| M 13 (Wear Protector) |
– | 2.5, 5.1, 7.7, 10.3, 12.9, 15 17.6, 20.2, 22.8, 25, 50, 75, 100 | 13 | 13 |
• All standard sets are available with base 2mm gauge block on request.
• Each gauge block is marked for size & serial number.
